Detailní informace
Kód produktu: 72 237
Detailní popis Megasat Campingman Kompakt
This fully automatic satellite system is optimally protected against air flow, by an aerodynamically…
This fully automatic satellite system is optimally protected against air flow, by an aerodynamically formed plastic hood, weather effects and dirt; the low installation height of the hood is 30 cm and has only little impact on the vehicle’s height. The built-in GPS-receiver is made for fast satellite search; Campingman is also equipped with a conventional receiver port. The new Shipman Compact can adjust to the selected satellite also on the road due to tracking system and GPS; thus, it is perfect for campers, caravans, yachts and vans. Moreover, preconfigured satellites are Astra 1, Astra 2, Astra 3, Astra 4, Hotbird, Thor, Atlantic Bird 3 and Eutelsat 9A. The systems are available as a Single or Twin version.
Technical Data:
Mirror size W 48 x H 24 cm, universal-LNB, frequency range 10,7 – 12,75 GHz, azimuth 360°, alignment time: approx. 1 – 2 min, dimensions of external unit: Campingman L 80 x W 68.5 x H 30 cm, Shipman L 80 x W 68.5 x H 31.2 cm, weight of of external unit: Campingman approx. 9.6 kg, Shipman 15.5 kg, dimensions control unit : Campingman W 12 x D 7.7 x H 3 cm, Shipman W 20.3 x H 3.5 x D 14 cm.
Scope of delivery:
External unit with cable, control unit, 2 x 12 m coaxial cable, cable routing to the roof
